The quality of the 400l brewery equipment manufactured by Micet Craft is the best in China. Because of its affordable price and small space requirements, it is called the best transition equipment from a small brewer to a commercial brewer. You can attract consumers through the unique brewing process and beer flavor. The 400l brewery equipment is produced and manufactured using food-grade 304/316 stainless steel, and you can also request to use copper for manufacturing. The appearance of the equipment is very beautiful. You can place the equipment in the center of the restaurant so that consumers can observe the beer-making process. This is an excellent marketing tool.
400L Brewery Equipment Specification
- Effective volume: 400L; Total volume: 500L
- Material: SUS304/SUS316 Stainless Steel
- Control system: PLC Siemens or PID Schneider/ABB brand
- Heating method: Electric/steam/direct fire heating
- Power: 16kw
- Voltage: 3 phase/380(220, 415,480…)v/50(60)Hz; Single Phase/220(110, 240…)v/50(60)Hz
- Brewing batch: 1-2 brew/day
- Heat transfer efficiency: ≥90%
- Polishing accuracy: ≤0.4μm
- Heat exchange area: 0.55㎡
- Required area: 40m²
400L Brewery Equipment Standard Configuration
Malt Milling Unit
- Particle adjustable rolling crusher
- Flexible or steel auger to directly lift the milled grain to mash tun
- Mash/Lauter tun, Boiling/Whirlpool tun 2 vessel combination
- Hot water tank and cold water tank for optional in special combinations
- Infusion or decoction brewing methods are designed exactly
- Stainless steel is popular because of easy maintenance and clean, copper cladding for optional
- Two stages or a single-stage heat exchanger for wort cooling
- Completely stainless steel integrated work platform
- Sanitary and efficient wort pump
- All pipings and fittings
- Standard stainless steel conical cylindrical fermentation tanks
- Single size or double size as brewhouse is commonly used in microbreweries
- Tanks quantity is exactly calculated by fermentation cycle for various beers
- All manhole, valves, pressure gauges, fittings, etc are included
- Standard stainless steel conical cylindrical fermentation tanks
- Single size or double size as brewhouse is commonly used in microbreweries
- Tanks quantity is exactly calculated by fermentation cycle for various beers
- All manhole, valves, pressure gauges, fittings, etc are included
Cooling Unit
- Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing
- Efficiency chillers or refrigerators with freon to supply cooling energy
- Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger
- All pipes, fitting, insulation materials are included
Controlling Unit
- Electrical controlling cabinet with temperature, on-off controlling for brewhouse
- Electrical controlling cabinet with temperature, on-off controlling for cooling parts
- Temperature controller, thermocouple, solenoid valves, etc are included
- PLC with touch screen panel for special request
400L Brewery Equipment Optional Configuration
- Craft beer is no need filtration which will keg filling for quick consumption
- Plate-Frame or Candle type DE
- Keg filling and rinsing machine
- Semiauto bottling machine with rinsing, filling, capping, labeling, etc
- Flash pasteurizer or tunnel pasteurizer is available
- Portable or fixed CIP system for cleaning the tanks
- Steam boiler for brewhouse heating
- Water treatment for brew water
- Oil-free air compressor
400L Brewery Equipment Advantages
- We can customize the equipment design as per customer brewing method and brewing beer types can make beer highest to 33 Plato.
- All Construction uses high-quality SUS 304 food-grade stainless steel, all pipes are SUS304, perfect 3mm inner shell and 2mm outer shell.
- All tanks are equipped with specially designed jackets to ensure heating and cooling efficiency. Both cone top and shell bottom have jackets, exchanging area are big enough.
- The headspace of our tanks is much bigger, the total volume does not include the cover headspace.
- 100%TIG welding process to weld the tank, jackets welding are all full welding by water, uniform dimpled cooling jacket to ensure no leaking and long life, welds passivated!
- Our polishing is overall mirror polishing, polishing 6 times to make Ra 0.4um mirror finish, can clean 360° without dead ends.
- Jacket testing 12 hours with air and water, jacket testing pressure is 5Bar, internal shell testing pressure is 4Bar, and before packing we will also have 48hours of water testing.
- Strict quality control and process inspection & testing system, which all the testing record will show on our data late with the tanks shipping, with checking the list and serial numbers to track.
- We insist on a high-end product line to manufacture our tanks, all components like chiller, exchanger, steam boiler, and Schneider/ABB electronics control systems all adopt international brands to ensure quality and convenient after-sales.
400L Brewery Equipment Details
Get 400L Brewery Equipment Price
If you want to know more about the 400l brewery equipment, you can contact us directly. We are available 24/7 via fax or email. You can also use the quick contact form below or visit our office. We would be happy to answer your questions. Micet Craft’s engineers can provide you with the most professional turnkey brewery solution!
